The following is a brief summary highlighting the main differences of these fuels. Much more comprehensive details of the fuel properties and compositions
1.Compressed Natural Gas or CNG is stored on the vehicle in high-pressure tanks - 20 to 25 MPa (200 to 250 bar, or 3,000 to 3,600 psi). Natural gas consists mostly of methane and is drawn from gas wells or in conjunction with crude oil production. As delivered through the pipeline system, it also contains hydrocarbons such as ethane and propane as well as other gases such as nitrogen, helium, carbon dioxide, sulphur compounds, and water vapour. A sulphur-based odourant is normally added to CNG to facilitate leak detection. Natural gas is lighter than air and thus will normally dissipate in the case of a leak, giving it a significant safety advantage over gasoline or LPG.
Sample cng station -CNG DAUGHTER SATION
L-CNG STATION
L-CNG dispensing device is consisted of LNG storage tank, unloading immersed pump, cryogenic piston pump, high-pressure vaporizer, sequence control panel, storage cylinder set, gas dispenser, pipeline and valve. The station control system includes PLC control system, gas alarm system, instrument system, flame detecting system (optional) and lighting system.
2. Liquefied Natural Gas or LNG is natural gas stored as a super-cooled (cryogenic) liquid. The temperature required to condense natural gas depends on its precise composition, but it is typically between -120 and -170°C (-184 and –274°F). The advantage of LNG is that it offers an energy density comparable to petrol and diesel fuels, extending range and reducing refuelling frequency.
The disadvantage, however, is the high cost of cryogenic storage on vehicles and the major infrastructure requirement of LNG dispensing stations, production plants and transportation facilities. LNG has begun to find its place in heavy-duty applications in places like the china , US, the UK and some countries in Europe. CHINA natural gas demand boost,now own more natural gas station than any other country.
LNG STATION :
3.Liquefied Petroleum Gas or LPG (also called Autogas) consists mainly of propane, propylene, butane, and butylene in various mixtures. It is produced as a by-product of natural gas processing and petroleum refining. The components of LPG are gases at normal temperatures and pressures. One challenge with LPG is that it can vary widely in composition, leading to variable engine performance and cold starting performance. At normal temperatures and pressures, LPG will evaporate. Because of this, LPG is stored in pressurised steel bottles. Unlike natural gas, LPG is heavier than air, and thus will flow along floors and tend to settle in low spots, such as basements. Such accumulations can cause explosion hazards, and are the reason that LPG fuelled vehicles are prohibited from indoor parkades in many jurisdictions.
LPG FILLING STATION
But there have another kind new fuel ,now some counry already begin use .
Hydrogen or H2 gas is highly flammable and will burn at concentrations as low as 4% H2 in air. For automotive applications, hydrogen is generally used in two forms: internal combustion or fuel cell conversion. In combustion, it is essentially burned as conventional gaseous fuels are, whereas a fuel cell uses the hydrogen to generate electricity that in turn is used to power electric motors on the vehicle. Hydrogen gas must be produced and is therefore is an energy storage medium, not an energy source. The energy used to produce it usually comes from a more conventional source. Hydrogen holds the promise of very low vehicle emissions and flexible energy storage; however, many believe the technical challenges required to realize these benefits may delay hydrogen’s widespread implementation for several decades.
Hydrogen can be obtained through various thermochemical methods utilizing methane (natural gas), coal, liquified petroleum gas, or biomass (biomass gasification), from electrolysis of water, or by a process called thermolysis. Each of these methods poses its own challenges.
